Nvidia GeForce 8800 GTX 756 MB

Нет изображения на мониторе, при включении системника. Graphics Processor GPU Name G80 GPU Variant G80-300-A2 Architecture Tesla Foundry TSMC Process Size 90 nm Transistors 681 million Density 1.4M / mm² Die Size 484 mm² Chip Package BGA-1449 Graphics Card Release Date Nov 8th, 2006 Generation GeForce 8 (8800) Predecessor GeForce 7 PCIe Successor GeForce 9 Production End-of-life Launch Price 599 USD Bus Interface PCIe 1.0 x16 Clock Speeds GPU Clock 576 MHz Shader Clock 1350 MHz Memory Clock 900 MHz 1800 Mbps effective Memory Memory Size 768 MB Memory Type GDDR3 Memory Bus 384 bit Bandwidth 86.40 GB/s Render Config Shading Units 128 TMUs 32 ROPs 24 SM Count 16 L2 Cache 96 KB Theoretical Performance Pixel Rate 13.82 GPixel/s Texture Rate 36.86 GTexel/s FP32 (float) 345.6 GFLOPS Board Design Slot Width Dual-slot Length 270 mm 10.6 inches TDP 155 W Suggested PSU 450 W Outputs 2x DVI 1x S-Video Power Connectors 2x 6-pin Board Number P355 SKU 0 Graphics Features DirectX 11.1 (10_0) OpenGL 3.3 OpenCL 1.1 (1.0) Vulkan N/A CUDA 1.0 Shader Model 4.0
