Материнская плата ECS MCP61SM-AM AM2

ECS MCP61SM-AM V.1.0A OEM Условно исправна. Для стабильной работы требуется замена конденсаторов. Без замены может выключаться при нагрузке на процессор. CPU: Socket AM2 with AMD Athlon 64 FX/ Athlon 64/ Athlon 64 X2 Dual-Core/ Sempron processor High-performance Hyper Transport CPU interface. Support transfer rate of 2000/1600/1200/800/400 mega-transfers per second. CHIPSET: Single chipset: NVIDIA GeForce 6100S GRAPHICS: On Chip (NVIDIA GeForce6100-based. 2D/3D graphic engine) Share Memory: Maximum up to 256MB MEMORY: 4 x 240-pin DDR2 DIMM Dual-channel DDR2 memory architecture Support DDR2 800/667/533/400 DDR2 SDRAM EXPANSION SLOTS: 1 x PCI Express x16 slot (also runs in x8 mode) 1 x PCI Express x1 slot 2 x PCI slots STORAGE: Support by NVIDIA GeForce 6100S 2 x Ultra DMA133/100/66 devices 2 x Serial ATA2 devices AUDIO: 8-channel audio Compliant with HD specification LAN: 10/100/1000MBPS Gigabit Lan REAR PANEL I/O: 1 x PS/2 keyboard & PS/2 mouse connectors 1 x Serial port (COM1) 1 x VGA port 1 x RJ45 LAN connector 4 x USB ports 1 x FireWire 1 x Audio port (Line-in, Line-out, Mic-in) INTERNAL I/O CONNECTORS & HEADERS: 1 x 24-pin ATX Power Supply connector 1 x 4-pin ATX 12V connector 1 x FDD connector 1 x IDE connector 2 x Serial ATA connectors 2 x USB 2.0 headers support additional 4 USB Ports 1 x COM2 header (optional) 1 x Front panel switch
