Студийный интерфейс RME digi 96/8 pad

Карта ввода/вывода для PC/Mac (S/PDIF, ADAT, AD/DA, 24 bit/96 kHz), PCI Дрова под любую win. Помогу с установкой. Варианты обмена... Лучше пишите. 5.1 Digital · Ultra-low jitter SPDIF: < 1 ns in PLL mode (44.1 kHz, optical in) · Ultra-low jitter ADAT: < 2 ns in PLL mode (44.1 kHz, optical in) · Input PLL ensures zero dropout, even at more than 40 ns jitter · Bitclock PLL for trouble-free varispeed in ADAT mode · High-sensitivity input stage (< 0.2 Vss input level) · Output voltage 0.8V (phono), 3.5V (XLR) · Supported sample rates: 32 / 44.1 / 48 / 64 / 88.2 / 96 kHz and variable (word clock) · Supports all known formats mono/stereo from 16 to 24 bit · Supports all known multi channel formats from 16 to 24 bit 5.2 Analog · Input sensitivity adjustable through jumper +4 dBu / -10 dBV · Dynamic range input: 105 dB (RMS unweighted, unmuted), 109 dBA · THD+N input: < -100 dB / < 0.001 % · Frequency response AD, -0.1 dB: 10 Hz - 20,3 kHz (sf 44.1 kHz) · Frequency response AD, -0.5 dB: 5 Hz - 44,8 kHz (sf 96 kHz) · Sample rates record: 32 / 44.1 / 48 / 64 / 88.2 / 96 kHz and variable (word clock) · Input impedance: 10 kOhm · Channel separation: > 110 dB · Analog output fixed +10 / +4 / -2 / -8 dBu @ 0 dBFS, and variable (fader) · Dynamic range output: 108 dB (RMS unweighted, unmuted), 112 dBA · THD+N output: -100 dB / 0.001% · Frequency response DA, -0.1 dB: 20 Hz - 20.8 kHz (sf 44,1 kHz) · Frequency response DA, -0.5 dB: 10 Hz - 44 kHz (sf 96 kHz) · Sample rates playback: 32 / 44.1 / 48 / 64 / 88.2 / 96 kHz and variable (word clock) · Ouput impedance: 75 Ohm · Channel separation: > 110 dB 5.3 Digital Interface · Inputs and outputs ground-free transformer coupled · Connectors: optical (TOSLINK), coaxial (phono), XLR, internal (CD-ROM/Sync-In / Out) · Formats: SPDIF, AES/EBU (Consumer/Professional), ADAT optical
